CAPSULE PRESSURE GAUGES

PP Series

Capsule Pressure GaugesPP002



Features

  • Low range with high accuracy
  • Compact design
  • These pressure gauges are well suited for low pressure measurement
  • Request a Quote
  • Product information
  • Product Range
Application Ideal for low pressure measurement of gaseous media like Burner monitoring, Gas production, Medical applications
Dial size 4”, 6”
Case SS304
Ring SS304
window Glass / Toughened Glass / Shatterproof glass
Dial Black figures on white background. Materials - Customizable
Pointer ‘0' Adjustable, Materials & Colors - Customizable
SENSING ELEMENT Capsule Diaphragm - SS316 or Brass (Soldered)
SOCKET SS316 / Copper Alloy
MOVEMENT SS304 / Copper Alloy
CONNECTIONS 3/8”, 1/2” BSP or NPT
RANGES 0 to 1000 mmwc upto 6000 mmwc, compound & vacuum 0 to 100 mbar upto 600 mbar, compound & vacuum
ACCURACY ±1% / ± 2% FSD
PROTECTION IP55
(MMWC) (MBAR)
0 - 400 0 - 40
0 - 600 0 - 60
0 - 1000 0 - 100
0 - 2000 0 - 200
0 - 4000 0 - 400
0 - 6000 0 - 600
