Hour RPM Meters; Hour Meter

P30 – 9387
P20 – 5918
P20 – 5552
P20 – 5501
P20 – 5491

Hour Meter

Diameter (mm)	Range (rpm)	Count (Maximum)	Voltage	Ref. Part No.	Movement	Dial	Illumination	Bazel	Features
52	NA	99999.9	12 V DC 24 V DC	P30 – 9387 – B	Not Applicable	Black / White	LED	Chromium plated Black painted	Mechanical type display.
52	NA	99999.9	12 V DC 24 V DC	P30 – 5918 – B	Not Applicable	Black	LED	Chromium plated White painted Black painted	LCD display with backlight. Microcontroller based design.

Hour rpm Meter

Diameter (mm)	Range (rpm)	Count (Maximum)	Voltage	Ref. Part No.	Movement	Dial	Illumination	Bazel	Features
85	0 to 3000	99999.9	12 V DC 24 V DC	P20 – 5501 – E	Air core	Black	LED	Chromium plated Black painted	Suitable for all vehicles, machines. LCD display hour counter with backlight.
85	0 to 3000	99999.9	12 V DC 24 V DC	P20 – 5552 – C	Air core	Black / White	Lamp	Chromium plated	Micro controller based design. Least count 0.1 hr Display capacity is 99999.9 hr
100	0 to 3500	99999.9	12 V DC 24 V DC	P20 – 5491 – C	Stepper Motor	Black / White	LED	Chromium plated Black painted	Suitable for all vehicles, machines. LCD display hour counter with backlight.

Hour RPM meter counts the hours, based on alternator signals, the signal is mostly taken from ‘W-Point’ and indicates the corresponding Engine rpm. Incorporated hour meter shows true engine hours. Suitable for most petrol and diesel engines. Very accurate and stable indication due to micro controller based aircore movement. LCD hour counter and back light provided for clear visibility at night condition. Hour counter starts counting when the speed of the engine reached above idle rpm.

Hour counter counts and displays the time of the vehicle or machine has been used. Suitable for all machines and all types of vehicles.Highly accurate and stable hour counting with microcontroller based design.
